Product Details

DA Electric, one of the best manufacturers and suppliers in China, now brings you high-tech precision drilling alumina ceramic pcb at competitive price from its professional factory. With the most advanced technology and high-end equipment introduced from America and Japan, as well as qualified staff, we can assure you the high quality, high precision and long lifespan of our products.

Basic Info

Type: Insulation Sheet
Material: Ceramic
Maximum Voltage: 20KV~100KV
Certification: SGS
Lead Time: 15-30days
Transport Package: Carton or Wooden Case Packaging
Origin: China
Application: Insulators
Chemistry: Organic Insulation
Thermal Rating: 250 250
Classification: Hybrid Insulation Materials
Color: White
Specification: 50x50x30cm

Product Description

Ceramic Substrates are used in many electronic applications where a thin insulating layer of thermally
stable material is required to conduct heat away from electronic components whilst electrically insulating
them, and material is 92%, 96%, 99%alumina, zirconia and ZTA.

Supply alumina ceramic substrate:
Thickness: 0.3 - 2mm
Size: 10 - 300mm, According to drawing.

Laser Cutting ceramic substrate:
Cutting the highest accuracy: +/- 0.02mm
Cutting Maximum size: 152.4 x 152.4 mm
Cutting Minimum aperture diameter: 0.1mm
Cutting Maximum thickness: 1.5mm

Product Name	Ceramic Substrates
Material	Alumina, Zirconia and Silicon Nitride Ceramic
Color	Black and White
Size	10-300mm
Thickness	0.3mm, 0.38mm, 0.5mm, 0.635mm,1mm, And According to drawings
Surface Roughness	Ra0.2
Tolerance	+/-0.01mm
Lead time	15 - 30days
Max. Working	1500 -1700 °C
Samples	Avaliable
Shipping	Air Express (DHL/UPS/TNT/ FedEx) or Ocean Shipping

Products Show:

Properties	Units	96% Al2O3	99% Al2O3	Zirconia	Silicon Nitride	Machinable Ceramic
Material Characteristics
Gas Permeability		0	0	0	0	0
Water Absorption	%	0%	0%	0%	0%	0.038%
Colour		White	Ivory	White	Grey	White
Density	g/cm³	3.7	3.85	6	3.2	2.7
Physical Characteristics
Hardness	Kg/mm²	1100	1400	1100	1600	1175
Modulus of Elasticity	Gpa	300	350	200	300	65
Flexural Strength	Mpa	300	340	1150	600	108
Compressive Strength	Mpa	2100	2200	2500	2500	488
Fracture Toughness	Mpam^1/2	3.5	4	12	6
Thermodynamic Property
Max Use Temperature	°C	1500	1650	1500	1800	800
Thermal Conductiviey	W/(m.k)	25	27.5	2.5	20	1.68
Thermal Expansion Coefficient	10^-6/°C	7.5	8	10	3.2	8.6
Thermal Shock Resistance	△T°C	200	200	250	600	200
Specific Heat	J/kg.K	860	860	500	500
Electrical Specification
Dielectric Strength	KV/mm	12	10	5		40
Dielectric Constant	εr	9.5	9.1	12	6	7
Volume Resistivity	Ω	≥10¹⁴	≥10¹⁴	≥10¹⁰	≥10¹⁴	≥10¹⁶
Dielectric Loss Angle		0.0002	0.0002	0.001
