Alumina ceramic PCB prototype manufacturer with Hi-Tech

XDPPCB23

Product Details Key Specifications/Special Features: Fastline provides one-stop service from PCB design, components sourcing, assembly and function test and final production built. We also provide PCB&PCBA clone or copy service and there is no MOQ . Specification: Board material: 5%-99%...

Quantity:

0.00

Unable to ship to shipping address, please feedback to us

Contact Now

add to cart

Buy Now

Verification Code

Message Content

Company Address

Country

Phone

Company Name

You can only upload 1 attachments at most
Supported formats: PDF,JPG,PNG,EXCEL,WORD,STP,IGS,DWG,DXF,PDF,STEP
The size of the uploaded file should not exceed 10MB

Product Details

Alumina ceramic PCB Specification:

Board material: 5%-99% (AL2O3) alumina ceramics

Board thickness: 1.0mm

Min hole size: 0.2mm

Min track width/space: 0.2mm/0.2mm

Copper thickness: 1 OZ

Solder mask: White

Silkscreen: Black

Surface finishing: ENIG

Producing Method: Hot pressing /Dry pressing

Ceramic PCB capability:

Item	Test Condition	unite	senior
material	Aluminium nitride Ceramic /Alumina 99.5%/Alumina 99%
Color status
average crystal size		μm	3-5
volume density		g/cm³	≧3.74
water absorption		%	0
Vickers hardness	Load4.9	Gpa	≧15
flexural Strength	Bending moment80mm	Mpa	≧324
Linear Coefficient of Thermal Expansion	20-500℃ 20-800℃	1×10- ˚mm/℃	605-7.5 6.5-8.0
thermal conductivity	20℃	W(m-k)	≧170
Dielectric intensity		Kv/mm	≧12
Volume Resistance	20℃ 300℃ 500℃	Ω-cm	≧1014 ≧1011 ≧109
Dielectric Constant	1MHz		9.3-10.6
dielectric loss	1MHz		3×10-4
Thermal - shock	850℃	times	≧7
roughness of the surface	Ra(λ2)	μm	0.20-0.75

Applications:

1. Electric appliance industry/Automotive industry/Mechanical industry

2. Engineering industry/Electrical heating element industry/LED Lighting Industry

Testing procedures for PCB board:

We perform multiple quality assuring procedures before shipping out any PCB board. These include:

1. Visual Inspection

2. Flying probe

3. Impedance control

4. Solder ability detection

5. Digital metallogenic microscope

6. AOI (Automated Optical Inspection)

Quotation requirement:

-Quantity

-Base material

-Board thickness

-Copper thickness

-Surface treatment

-Color of solder mask and silkscreen

Primary Competitive Advantages:

-Experienced Staff

-Green Product

-Guarantee/Warranty

-International Approvals

-Packaging

-Price

-Product Features

-Product Performance

-Prompt Delivery

-Quality Approvals

-Reputation

-Service

-Small Orders Accepted

-Country of Origin

Main Export Markets:

-Asia

-Australasia

-Central/South America

-Eastern Europe

-Mid East/Africa

-North America

-Western Europe

-Special Features of XingDa:

Fastline provides one-stop service from PCB design, components sourcing, assembly and function test and final production built.
We also provide PCB&PCBA clone or copy service and there is no MOQ.

Please contact with us for more information:

Ms. Sicen Hu

Mobile phone:+86-15919900196

Skype: xingdapcbsales3

Email: sales3@xdpcba.com

Hot Tags: Alumina ceramic PCB prototype manufacturer with Hi-Tech, China, manufacturers, suppliers, factory, customized, OEM, ODM
