Carbon Ink PCB Board
XDCPCB51
Product Detail Basic Info Specification: ISO9002, UL, SGS Origin: China Product Description Our Production Capability For Other PCB 1)Layer: 1-16 2)MAX. Board Size For Single/Double-Sided PCB: 800*550 3)Solder Mask: Green/red/blue/white/yellow. etc, as required 4)Base Material: Fr-4, cem-1,...
Quantity:
US $0.00
Unable to ship to shipping address, please feedback to us
- Product Details
Product Detail
Basic InfoSpecification:ISO9002, UL, SGS
Origin:China
Product Description
Our Production Capability For Other PCB
1)Layer: 1-16
2)MAX. Board Size For Single/Double-Sided PCB: 800*550
3)Solder Mask: Green/red/blue/white/yellow. etc, as required
4)Base Material: Fr-4, cem-1, cem-3, ceramics, high tg cooper(CCL)
5)Board Thickness: 0.2mm-4.5mm
6)Min. Line Width: 0.1mm(4mil)
7)Min. Line Space: 0.1mm(4mil)
8)Min. Hole Size: 0.2mm
9)Surface Finishing: HASL/lead-free HASL, immersion gold/silver/tin, chemical gold, plated gold, OSP, carbon ink, gold finger
10)Hole Plating Tolerance PTH Thickness: >0.025mm
11)PTH Tolerance: ± 0.075mm
12)NPTH Tolerance: ± 0.05mm
13)Hole Position Tolerance: ± 0.05mm
14)Outline Dimension Tolerance: ± 0.15mm
15)Hole Resistance: <300U
16)Dielectric Strength: >1.6kv/mm
17)Current Breakdown: 10A
18)Peel Strength: 1.5n/mm
19)Solder Mask Abrasion: >5H
20)Inflammability: 94vo
21)Certificate: ISO9002, UL, SGS
22)Special Technology: Blind and buried vias, impedance control, BGA, semiconductor vias, silver-filled hole
23)Form: Punching, routing, v-cut, beveling
| base material | fr-4 epoxy resin |
| board thickness | 0.2mm-3.2mm |
| cooper thickness | 1/2OZ 1OZ 2OZ 3OZ |
| min.hole size | 0.2mm(8mil) |
| min.line width | 0.1mm(4mil) |
| min.line spacing | 0.1mm(4mil) |
| surface finishing | carbon ink |
| form | punching,routing,v-cut,beleling |
Contact Now
DA Electric, one of the best manufacturers and suppliers in China, now brings you high-tech carbon ink pcb board at competitive price from its professional factory. With the most advanced technology and high-end equipment introduced from America and Japan, as well as qualified staff, we can assure you the high quality, high precision and long lifespan of our products.
