multilayer pcb

Fast delivery ENIG multilayer pcb circuit board

XDPCB-009
Provide free DFM Checking , We can suggest 6 layer PCB stack-up

Copper Thickness: Max to 6 oz inner copper, 12 oz outer copper

Min Hole: 0.15mm by mechanical drilling 0.1mm by laser

PCB Thickness :0.4mm – 6.5mm

Surface Process: Immersion gold ,HASL-LF,Hard Gold,Immersion Tin

Soler Mask: Green Yellon White Black or custom

Silkscreen: White Black Yellow or custom

Accept 6 layer PCB with Blind or buried hole

100% Testing
Quantity:
US $0.00
Unable to ship to shipping address, please feedback to us
Contact Now
add to cart
Buy Now
captcha
  • You can only upload 1 attachments at most
  • Supported formats: PDF,JPG,PNG,EXCEL,WORD,STP,IGS,DWG,DXF,PDF,STEP
  • The size of the uploaded file should not exceed 10MB

Fast delivery multilayer pcb 6 layers ENIG pcb printed circuit board pcb circuit board

Specification:
Lead free compatible FR4 Laminate
TG170 ℃，UV Blocking/AOI compatible
High heat resistance
Lower Z-axis CTE
Excellent through-hole reliability
Excellent anti-CAF performance
Low water absorption
Excellent mechanical processibility
multilayer pcb 6 layers ENIG pcb printed circuit board pcb circuit boardmultilayer pcb 6 layers ENIG pcb printed circuit board pcb circuit boardmultilayer pcb 6 layers ENIG pcb printed circuit board pcb circuit board
multilayer pcb 6 layers ENIG pcb printed circuit board pcb circuit board
Basic information:
Layer:6
Surface finish: ENIG
Thickness:1mm
Copper weight:1OZ
Stack up: 2 core
multilayer pcb 6 layers ENIG pcb printed circuit board pcb circuit board
multilayer pcb 6 layers ENIG pcb printed circuit board pcb circuit board
6 Layer Multilayer PCB parameter:

Number of Layer6 Layer
Order Quantity1 to 50,000
Board ShapeRetangular,round,slots,cutouts,complex,irregular
Board TypeRigid, Flexible, Rigid-flexible
Board MaterialFR-4 glass epoxy, FR-4 high Tg, Rohs compliant,Aluminum,Rogers,etc.
Board CuttingShear,V-score,Tab-routed
Board Thickness0.2-4.0mm, Flex 0.01-0.25mm
Copper Weight1.0, 1.5, 2.0 ,3.0,4OZ
Solder MaskDouble-sided green LPI,Also support Red,White,Yellow,Blue,Black
Silk ScreenDouble-sided or single-sided in white,yellow,black,or negative
Silk Screen Min Line Width0.006'' or 0.15mm
Max Board Dimensions20 inch*20inch or 500mm*500mm
Min Trace/Gap0.10mm, or 4mils
Min Drill Hole Diameter0.01'',0.25mm, or 10mils
Surface FinishHASL,Nickle,Immersion Gold,Immersion Tin,Immersion Silver,OSP,etc.
Board Thickness Tolerance±10%
Copper Weight Tolerance± 0.25 oz
Minimal Slot Width0.12'', 3.0mm, or 120mils
V-Score Depth20-25% of board thickness
Design File FormateGerber RS-274,274D,Eagle and AutoCAD's DXF,DWG
