Fr4 led pcb board lead-free hasl pcb for lighting industry

0486-LED PCB

Introducing our innovative elongated LED PCB board.
Led pcb for residential, commercial, and industrial areas.
Measures 1140mm × 30mm
Unique and complex, featuring more than 320,000 holes per square meter

Quantity:

US $0.00

Unable to ship to shipping address, please feedback to us

Contact Now

add to cart

Buy Now

Verification Code

Message Content

Company Address

Country

Phone

Company Name

You can only upload 1 attachments at most
Supported formats: PDF,JPG,PNG,EXCEL,WORD,STP,IGS,DWG,DXF,PDF,STEP
The size of the uploaded file should not exceed 10MB

Fr4 led pcb board lead-free hasl pcb for lighting industry

Specification

Name	Multilayer PCB
Material	Fr4
Layers	2 layers PCB
Solder Mask Color	White
Size	1140mm × 30mm
Copper Thickness	2 oZ
Surface Treatment	Lead-free HASL
Application	Lighting industry

Elongated LED PCB board measuring 1140mm × 30mm.

The unique design pushes boundaries, catering to diverse lighting applications in residential, commercial, and industrial settings. This LED PCB board offers superior thermal management and electrical conductivity with its 2-layer FR4 substrate and 2oz copper thickness. With over 320,000 holes per square meter, the high hole density presents production challenges, requiring meticulous attention and advanced testing protocols. XingDa's cutting-edge LED PCB benefits various applications and industries, including automotive and medical.The white solder mask ensures a clean design, environmental protection, and features a lead-free HASL surface finish for enhanced durability.

As an professional PCB manufacturer with more than 10 years of experience, XingDa's LED PCB offers versatility, durability, and efficiency. Our commitment to meeting customer demands is evident in this revolutionary product that redefines LED PCB design for multiple applications: LED PCB for residential lighting: Enhances ambiance and energy efficiency in homes. LED PCB for commercial lighting: Creates inviting atmospheres in offices and retail spaces. LED PCB for industrial lighting: Optimizes lighting in factories and warehouses.

XingDa's LED PCB suits diverse industries: Automotive LED circuit board: Provides reliable solutions for automotive lighting systems. Telecom LED PCB: Supports high-speed data transmission in telecommunication infrastructure. Medical LED circuit board: Contributes to accurate diagnostics in medical devices and equipment. With customizable options like the 94V-0 LED PCB and custom LED PCB capabilities, XingDa's innovative solutions cater to various needs, such as: PCB for LED indoor light PCB for LED outdoor light PCB for downlight LED panel PCB LED circuit board.

The aluminium PCB LED board ensures durability, while the PCB LED module enables easy integration of LED lighting system

Value	Specification
Material	FR-4, FR1,FR2; CEM-1, CEM-3,Rogers,Teflon,Arlon,Aluminum Base, Copper Base,Ceramic, Crockery, etc.
Remarks	High Tg CCL is Available(Tg>=180℃)
Finish Board Thickness	0.2 mm-6.00mm(8mil-126mil)
Surface Finish	Gold finger(>=0.13um), Immersion Gold(0.025-0075um), Plating Gold(0.025-3.0um), HASL(5-20um), OSP(0.2-0.5um)
Shape	Routing、Punch、V-cut、Chamfer
Surface Treatment	Solder Mask(black, green, white, red, blue, thickness>=12um, Block, BGA)
	Silkscreen(black, yellow, white)
	Peel able-mask(red, blue, thickness>=300um)
Minimum Core	0.075mm(3mil)
Copper Thickness	1/2 oz min; 12oz max
Min Trace Width & Line Spacing	0.075mm/0.1mm(3mil/4mil)
Min Hole Diameter for CNC Drilling	0.1mm(4mil)
Min Hole Diameter for Punching	0.6mm(35mil)
Biggest panel size	610mm * 508mm
Hole Position	+/-0.075mm(3mil) CNC Drilling
Conductor Width(W)	+/-0.05mm(2mil) or +/-20% of original
Hole Diameter(H)	PTHL:+/-0.075mm(3mil)
	Non PTHL:+/-0.05mm(2mil)
Outline Tolerance	+/-0.1mm(5mil) CNC Routing
Warp & Twist	0.70%
Insulation Resistance	10Kohm-20Mohm
Conductivity	<50ohm
Test Voltage	10-300V
Panel Size	110 x 100mm(min)
	660 x 600mm(max)
Layer-layer misregistration	4 layers:0.15mm(6mil)max
	6 layers:0.25mm(10mil)max
Min spacing between hole edge to circuitry pattern of an inner layer	0.25mm(10mil)
Min spacing between board outline to circuitry pattern of an inner layer	0.25mm(10mil)
Board thickness tolerance	4 layers:+/-0.13mm(5mil)
