Cooking Robot&pcba
sh008
This is a type of PCBA boards for cooking robot. Our PCBA boards are widely used in Medical facility,cooking robot, Communications industry, Household appliances, Consumer Electronics, electrical equipment and artificial intelligence industry, etc. America, Europe, Australia, Korea, Japan are main market of our business. At the same time, we are expand our business to emerging market like the Middle East, Africa, Southeast Asia.
Quantity:
0.00
Unable to ship to shipping address, please feedback to us
Overview

FAQ
1. When can I get the price?
A. We usually quote within 24 hours after we get your inquiry. If you are very urgent to get the price, please call us or tell us in your email so that we will regard your inquiry priority.
2. How can I get a sample to check your products quality?
A: After price confirmation, you can require for samples to check our products quality. We accept 5-10 pieces.
3. What is needed for Quotation of PCBA?
A. Gerber files, BOM and PCB specifications.
4. Are my PCB files safe when I submit them to you for manufacturing?
A: Your files are held in complete safety and security.We protect the intellectual property for our customers in the whole process.. All documents from customers are never shared with any third parties.
5. How about the lead time?
A: Sample: 2 to 3 weeks; Mass production: 3 to 4 weeks
The lead time depends on your final confirmation of the quantity.
6. How about your product's quality ?
A: All material was verified by SGS, reach to ROHS standard, quality control under ISO9000 system, finished PCBA 100% tested before shipping.

| PCB Manufacture Capability | |
| Item | Specification |
| Material | FR-4, FR1,FR2; CEM-1, CEM-3,Rogers, Teflon,Arlon,Aluminum Base, Copper Base,Ceramic, Crockery, etc. |
| Remarks | High Tg CCL is Available(Tg>=170℃) |
| Finish Board Thickness | 0.2 mm-6.00mm(8mil-126mil) |
| Surface Finish | Gold finger(>=0.13um), Immersion Gold(0.025-0075um), Plating Gold(0.025-3.0um), HASL(5-20um), OSP(0.2-0.5um) |
| Shape | Routing、Punch、V-cut、Chamfer |
| Surface Treatment | Solder Mask(black, green, white, red, blue, thickness>=12um, Block, BGA) |
| Silkscreen(black, yellow, white) | |
| Peel able-mask(red, blue, thickness>=300um) | |
| Minimum Core | 0.075mm(3mil) |
| Copper Thickness | 1/2 oz min; 12oz max |
| Min Trace Width & Line Spacing | 0.075mm/0.075mm(3mil/3mil) |
| Min Hole Diameter for CNC Drilling | 0.1mm(4mil) |
| Min Hole Diameter for Punching | 0.6mm(35mil) |
| Biggest panel size | 610mm * 508mm |
| Hole Position | +/-0.075mm(3mil) CNC Drilling |
| Conductor Width(W) | +/-0.05mm(2mil) or +/-20% of original |
| Hole Diameter(H) | PTHL:+/-0.075mm(3mil) |
| Non PTHL:+/-0.05mm(2mil) | |
| Outline Tolerance | +/-0.1mm(4mil) CNC Routing |
| Warp & Twist | 0.70% |
| Insulation Resistance | 10Kohm-20Mohm |
| Conductivity | <50ohm |
| Test Voltage | 10-300V |
| Panel Size | 110 x 100mm(min) |
| 660 x 600mm(max) | |
| Layer-layer misregistration | 4 layers:0.15mm(6mil)max |
| 6 layers:0.25mm(10mil)max | |
| Min spacing between hole edge to circuitry pattern of an inner layer | 0.25mm(10mil) |
| Min spacing between board outline to circuitry pattern of an inner layer | 0.25mm(10mil) |
| Board thickness tolerance | 4 layers:+/-0.13mm(5mil) |
