Professional Customize Design EMI Shielding Flexible PCB Factory

FPC26
EMI Shielding Flexible PCB is our specialty. The double-sided flexible circuit board includes a flexible substrate layer, an EMI shielding film disposed on the flexible substrate layer, and an insulating layer adhered on the EMI shielding film; the EMI shielding film is disposed on the EMI shielding film. Above the exposed copper portion, electrical connection between the exposed copper portions is achieved. This simplifies the manufacturing process of flexible circuit boards and saves production costs.
Quantity:
US $0.00
Unable to ship to shipping address, please feedback to us
Contact Now
add to cart
Buy Now
captcha
  • You can only upload 1 attachments at most
  • Supported formats: PDF,JPG,PNG,EXCEL,WORD,STP,IGS,DWG,DXF,PDF,STEP
  • The size of the uploaded file should not exceed 10MB
  • Product Details

About us

XINGDA Electric, one of the best manufacturers and suppliers in China, now brings you EMI Shielding Flexible PCB at competitive price from its professional factory. With the most advanced technology and high-end equipment introduced from America and Japan, as well as qualified staff, we can assure you the high quality, high precision and long lifespan of our products.

EMI Shielding Requirements In Common Applications

Medical Systems:

MRIs

Infusion pumps
Patient monitoring systems


Advantages
Less space taken up on the board
For heavy-duty applications the lid can also be secured by soldering it to the clips and some of the pins
Many different clips and pins are available for mounting the PCB shielding can to the PCB.

Our FPC

FPC Tech Specification

Items

Capabilities

Layers

FPC:1 to 6 Layers, Rigid Flex: 2 to 10 Layers

Regular Base Materials

Kapton,Polyimide(PI), Polyester(PET), FR4

Base Copper Thickness

1/3 oz to 8oz

Regular Base Material Thickness

12.5um to 50um(FPC)

0.1mm to 3.2mm(Rigid)

Regular Coverlay Thickness

27um to 50um

Regular Adhesive Thickness

12um to 25um

Blind or Buried Vias

Yes

Impedance Control

Yes
