Polyimide Fpcb

FPC018
There are polyimide and polyester material for fpcb. Polyimide is more commonly used for fpcb with its high electrical properties and chemical properties. This is a kind of polyimide fpcb with 1oz copper, 0.2mm board thickness and immersion gold surface finish. We are now producing one kind of polyimide fpcb for our new Brazil customer used for automotive speedometer.
Quantity:
0.00
Unable to ship to shipping address, please feedback to us
Contact Now
add to cart
Buy Now
captcha
  • You can only upload 1 attachments at most
  • Supported formats: PDF,JPG,PNG,EXCEL,WORD,STP,IGS,DWG,DXF,PDF,STEP
  • The size of the uploaded file should not exceed 10MB
  • Product Details

FPC Board Capability

Material: Polyimide / Polyester

Counts Flex: 1~8L; Rigid-Flex: 2~8L

Board Thickness: Min.0.05mm; Max. 0.3mm

Copper Thickness: 1/3 oz --- 2 oz

CNC Drill Size (Max): 6.5mm

CNC Drill Size (Min): Flex: 0.15mm

Holes Location Tolerance: ±0.05mm

Coverlay Drill Size (Min): 0.6mm

Hole to Coverlay Opening Windows (Min): 0.15mm

Min Line Width / Spacing: 0.1/0.1mm

Copper Thickness on Hole Wall: Flex:12-22μm

Min Pad Size:φ0.2mm

Etch Tolerance Finished line width tolerance: ±20%

Pattern Registration Tolerance:±0.1mm (Working Panel Size: 250*300mm)

Coverlay Registration Tolerance: ±0.15mm

Solder Mask Registration Tolerance: ±0.2mm

Min. Solder Mask Dam: 0.1mm

Misregistration Tolerance: ±0.30mm

Surface Finish Plating: Ni / Au ; Chemical Ni / Au ; OSP

Our Advantages

1. Technique advantage

We have wave soldering machines, SMT machines and other the most advanced equipment to ensure productions’ efficiency and quality.

2. Talents advantage

Our company actively introduce high-tech talents and tens of senior mechanics. Meanwhile, we’ve cooperated with many colleges and set up printed circuit board major, so that we have many professional employees introduced every year.

3. Experience advantage

Our company have more than 10 years’ experience in PCB/FPCB &

assembly. We’ve cooperated with many well-known enterprises all round the world. We’ve build up long-term business relationship with them and have accumulated very rich experience, which makes us be able to meet the needs of different clients.

Products Show



FAQ

1.Are you a trade company or a manufacturer?

A. We are an ISO, UL approved manufacturer specialized in pcb manufacturer, pcb assembly and components soldering and testing, OEM & ODM service are available.

2.What are the payment term?

A. T/T,L/C,Western Union,Paypal.

3.What is needed for quotation?

A. PCB: Quantity, Gerber file and Technic requirements(material,surface finish treatment, copper thickness,board thickness ,...)

PCBA: Besides the above, BOM is also needed.

4. Are my files safe?

A. Your files are held in complete safety and security.We protect the intellectual property for our customers in the whole process. All documents from customers are never shared with any third parties.

5.  What is your main market?

A: North America, South America, West Europe and Australia.
