We can produce all kinds of Flex PCBS, and get 100% satisfaction from our clients!

We are SHENZHEN XING DA Electronic Technology Co., Ltd. XD is a professional PCB and PCBA manufacturer with great reputation, specializing in printed circuit boards(up to 28 layers) and PCB assembly, We mainly offer high-precision single-side, double-side, multilayer printed circuit boards, led aluminum printed circuit board, customers components procurement and PCB assembly(SMT) business.



Production capacity of FPC

-Finished board dimensions 10 x 15, 250 x 380mm

-Finished board thickness tolerance ±2 mils

-Drill hole diameter 0.15mm - 6.7mm

-Inner layer dielectric thickness (1/2 mils PI with 15um adhesive) 0.0275mm - 0.1mm

-Hole diameter tolerance of PTH ±2 mils

-Hole diameter tolerance of NPTH ±1 mil

-Hole position tolerance (compared with Gerber data) ±1 mil

-Thickness of PTH hole copper 8μm - 30μm

-Solder mask alignment tolerance ±3mil

-Tolerance after etching generally ± 30, 15% for impedance

-Tolerance of image to image (minimum) ±3 mils

-Tolerance of image to edge (minimum) ±2 mils

-Cover layer registration (minimum) 6 mils

-Punching hole diameter 0.1mm - 5.0mm

-Tolerance of pasting adhesive and stiffener ±0.3mm

-Punching die dimension tolerance (hard die) ±4 mils

-Punching die dimension tolerance (soft die) ±12 mils

-Impedance tolerance (minimum) ± 10%

-SMT tolerance and pitch width (minimum) ±4 mils

Certification



Advantages of our FFC

1.Professional & experienced engineers

2.Offer technology support

3.Product warranty

4.Competitive price

5.More than 10 years experiences

6.OEM factory

7.Lead time:3-7 days

8.100% inspection before delivery

9.Making a sample quickly , delivery rapidly are our traits.

Exhibition Show

Applications of carbon FPC

1. Display / Notebook PC & Tablet PC / Flat panel display

2. Smart phone / Cell Phone

3. Flat screen TV / Professional TV

4. Printer / Scanner / FAX machine / Copier

5. Sound Box / Acoustics

6. MP3 / MP4

7. CD/ DVD

8. Digital camera

9. Robot / Industrial / Projector / Handy terminal / Amusement

10. Car electronics

11. Toy for children

12. AV equipment / Medical equipment / Digital measurement instrument
