LED Strip Digital Display FPC
FPC28
XinDa company has years of experiences about LED strip Digital Display FPC . FPC is mainly used in mobile phones, laptops,tablet, PDAs, digital cameras, LCM and many other products. We can produce more low thin ,low cost and more flexible LED strip Digital Display FPC as we are working on improving technology during many years production.
Quantity:
US $0.00
Unable to ship to shipping address, please feedback to us
Technical Detail for LED strip Digital Display FPC:
The Application for FPC
FPC can be used in different areas.
The following picture is the LED strip Digital Display FPC
Why us (Our FPC Advantage)?
Quality
Our UL/Rohs standards insure quality assemblies from start to finish. Whether it's a simple custom product or a complex turnkey production run, XD will adhere to the highest quality standards.
Capable
XD offers the latest in assembly capabilities and qualifications insuring that quality is built into every product we produce.
Protecting your interests
Protecting your Intellectual Property is job one! Our staff of trained professionals are all working under a strict confidentiality contract and treat your important documentation as they would their own.
Flexibility
We pride ourselves on our ability to custom tailor programs around our customers' needs. We take time to listen to your unique business needs and then set out to surpass them.
FAQ:
Q1: What's files do you use in the bare board fabrication?
A:Gerber RS-274X,274D,Eagle and AutoCAD's DXF,DWG
Q2: Will our PCB files be checked?
A: Yes. Your data will be checked by our Engineers Team. If we find any technical issues or have any inquiries we will contact you and solve the problems together.
Q3:What's files do you need in the PCBA projects?
A:Exclude the pcb file, the PNP(Pick and Place) file and Components Position file also needed.
Q4: How can i know the processing about my PCB or PCBA order?
A: Each Customer will have a sale to contact with you. XD working hours: AM9:00-PM7:00 (Beijing Time) from Monday to Friday. We will reply your email in 2 hours in our working time. And you also can contact with our sale's cell phone if urgent.
Q5: Dose our product will be tested before shipment?
A: Yes, we could provide Function Circuit Testing if you provide us the testing methods.
| Flexible PCB Process Capability | ||
| No | Item | Technical data |
| 1 | Flexible layers | 1~8 layers |
| 2 | Minimum Trace and Space | 12&18um(base Cu):0.075/0.075mm ;35um(base Cu):0.1/0.1mm |
| 3 | Minimum Space Between Coverlay Openings | 0.2mm |
| 4 | Edge of Coverlay Opening to Trace | 0.20mm(preferred) |
| 5 | Minimum Space between coverlay and solder pad | 0.15mm |
| 6 | Polyimide Films | 0.5 mil (12.5), 1 mil (25), 2 mils (50), 3 mils (75), |
| 4mils(100), 5 mils(125) as customer request | ||
| 7 | Thermobond Adhesives | Acrylic/Modified Acrylic, Modified Epoxy, Polyimide |
| 8 | Copper Foils (RA or ED) | 1/3oz (12), 1/2oz (18), 1oz (35), 2oz (70) |
| 9 | Stiffeners | Polyimide, rigid FR4, PSA, metal, or customer |
| supplied&requested | ||
| 10 | FR-4 in Multi-layer Flex circuit | Laminated to flex circuit to create rigid flex boards, |
| typically with vias. | ||
| 11 | Surface Finish | Electroless Ni/Au, Electrolytic soft/hard gold, |
| Tin plating,,Imm.Tin,Entek/OSP | ||
| 12 | Solder Resists | Coverlay, Photo-Imagable Resist |
| 13 | Hole tolerance | ±0.05mm |
| 14 | Smallest Drill Size | 0.2mm |
| 15 | Largest Drill Size | 6.35mm |
| 16 | Smallest Slot Width | 0.35mm |
| 17 | Min.space between holes | 0.15mm |
| 18 | Minimum conductor edge to | ≥0.1mm |
| outline edge | ||
| 19 | Minimum space between | ± 0.15mm |
| coverlay and conductor | ||
| 20 | Hole to outline edge | ≥ 0.10mm |
| 21 | Tooling tolerances | Knife(Soft) tooling : ± 0.25mm |
| Steel(Hard) tooling : ± 0.05mm | ||
| CNC drill/rout : ± 0.10mm | ||
| 22 | Maximum Layer to Layer | ± 0.10mm |
| Mis-registration | ||
| 23 | Copper Plated Thickness (PTH only) | 8~15um;20~30um;30~70um(special) |
| 24 | Au thickness | Electroless Ni/Au Ni:2~6um;Au:0.035~0.075um |
| Electrolyticsoft/hardgoldNi:2~9um;Au:0.035~0.1um | ||
