FR4 Carbon pcb board automotive air conditioning door sensors carbon printing pcb
Carbon-pcbgate-0001
Medical controller FPC. remote control FPC. FPC control board FPC. impedance control FPC. lcd controller FPC. Flex Circuit FPC Flex PCB.controlled rigid-flex pcb. controlled rigid flex prototype flexible pcb.
Quantity:
US $0.00
Unable to ship to shipping address, please feedback to us
| FR4 Carbon pcb board automotive air conditioning door sensors carbon printing pcb |
| Specification |
| Name | Electrodes FPC boards |
| Material | PC |
| Layers | Single layer PCB |
| Solder Mask Color | Green hydrophobic,UV330 |
| Size | 72mm × 32mm |
| Copper Thickness | None |
| Surface Treatment | The connectors are silver, also have carbon and silver chloride electrodes |
| Resistance value | 400 OHM plus or minus 20% ,(320OHM -480 OHM ) |
| Application | FPC electrodes for medical testing |
Xing Da, a company with over a decade of experience in producing high-quality FPC circuit boards, offers a range of electrode FPCs with various features, materials, and applications across different industries.
This specialized electrode FPC described in this video offers several key features:
1.Green hydrophobic mask: water-proof mask,water proof solder mask ensuring water proof and long-lasting durability for use in diverse environments and industries.
2.Silver connectors: Providing superior conductivity and corrosion resistance for reliable and efficient performance.
3.Carbon and silver chloride electrodes: Offering versatility in electrochemical applications and ensuring accurate, stable measurements.
4.Flex board with UV solder masks:Providing UV protection
5.FPCs with 400Ω ±20% resistance: Accurate and stable for sensitive applications
1.Green hydrophobic mask: water-proof mask,water proof solder mask ensuring water proof and long-lasting durability for use in diverse environments and industries.
2.Silver connectors: Providing superior conductivity and corrosion resistance for reliable and efficient performance.
3.Carbon and silver chloride electrodes: Offering versatility in electrochemical applications and ensuring accurate, stable measurements.
4.Flex board with UV solder masks:Providing UV protection
5.FPCs with 400Ω ±20% resistance: Accurate and stable for sensitive applications
These electrode FPCs are mainly used in medical laboratory testing, where they contribute to global innovation in the biotechnology market through portable diagnostics and data collection. Specifically, they are crucial components in equipment designed for detecting bacteria and infectious diseases.
Xing Da's expertise in FPC production also extends to various specifications and materials, including:
Conductive electrodes FPC, Electrodes FPC, and Medical test electrodes FPC for optimal performance in medical testing
Flex board for research lab applications, providing precise and reliable solutions for scientific experiments
Flex pcb with transparent PC fpc for enhanced visibility in various applications
FPC with Green hydrophobic solder mask, ensuring moisture resistance and durability
Flexible boards with UV solder mask for protection against UV radiation and enhanced performance
Carbon printing FPC and Silver printing FPC, catering to specific material requirements
Flex circuit board with resistance value 400Ω ±20%, providing accurate and stable resistance for sensitive applications
Conductive electrodes FPC, Electrodes FPC, and Medical test electrodes FPC for optimal performance in medical testing
Flex board for research lab applications, providing precise and reliable solutions for scientific experiments
Flex pcb with transparent PC fpc for enhanced visibility in various applications
FPC with Green hydrophobic solder mask, ensuring moisture resistance and durability
Flexible boards with UV solder mask for protection against UV radiation and enhanced performance
Carbon printing FPC and Silver printing FPC, catering to specific material requirements
Flex circuit board with resistance value 400Ω ±20%, providing accurate and stable resistance for sensitive applications
In addition to medical applications, Xing Da also specializes in producing electrode FPCs for other related industries, such as:
flexible circuit board for food safety industry: Ensuring safety standards and quality control in food production and processing
flexible printed circuitn for Environmental test industry: Facilitating accurate analysis and monitoring of various environmental factors
flexible printed circuit boards for indoor air quality monitoring solutions: Helping maintain healthy and safe indoor environments by measuring air quality parameters
flexible circuit board for food safety industry: Ensuring safety standards and quality control in food production and processing
flexible printed circuitn for Environmental test industry: Facilitating accurate analysis and monitoring of various environmental factors
flexible printed circuit boards for indoor air quality monitoring solutions: Helping maintain healthy and safe indoor environments by measuring air quality parameters
In conclusion, Xing Da's comprehensive range of electrode FPCs caters to various industries and applications, offering innovative and high-quality solutions tailored to clients' needs.
PCBProduct Capacity
| Value | Specification |
| Material | FR-4, FR1,FR2; CEM-1, CEM-3,Rogers,Teflon,Arlon,Aluminum Base, Copper Base,Ceramic, Crockery, etc. |
| Remarks | High Tg CCL is Available(Tg>=180℃) |
| Finish Board Thickness | 0.2 mm-6.00mm(8mil-126mil) |
| Surface Finish | Gold finger(>=0.13um), Immersion Gold(0.025-0075um), Plating Gold(0.025-3.0um), HASL(5-20um), OSP(0.2-0.5um) |
| Shape | Routing、Punch、V-cut、Chamfer |
| Surface Treatment | Solder Mask(black, green, white, red, blue, thickness>=12um, Block, BGA) |
| Silkscreen(black, yellow, white) | |
| Peel able-mask(red, blue, thickness>=300um) | |
| Minimum Core | 0.075mm(3mil) |
| Copper Thickness | 1/2 oz min; 12oz max |
| Min Trace Width & Line Spacing | 0.075mm/0.1mm(3mil/4mil) |
| Min Hole Diameter for CNC Drilling | 0.1mm(4mil) |
| Min Hole Diameter for Punching | 0.6mm(35mil) |
| Biggest panel size | 610mm * 508mm |
| Hole Position | +/-0.075mm(3mil) CNC Drilling |
| Conductor Width(W) | +/-0.05mm(2mil) or +/-20% of original |
| Hole Diameter(H) | PTHL:+/-0.075mm(3mil) |
| Non PTHL:+/-0.05mm(2mil) | |
| Outline Tolerance | +/-0.1mm(5mil) CNC Routing |
| Warp & Twist | 0.70% |
| Insulation Resistance | 10Kohm-20Mohm |
| Conductivity | <50ohm |
| Test Voltage | 10-300V |
| Panel Size | 110 x 100mm(min) |
| 660 x 600mm(max) | |
| Layer-layer misregistration | 4 layers:0.15mm(6mil)max |
| 6 layers:0.25mm(10mil)max | |
| Min spacing between hole edge to circuitry pattern of an inner layer | 0.25mm(10mil) |
| Min spacing between board outline to circuitry pattern of an inner layer | 0.25mm(10mil) |
| Board thickness tolerance | 4 layers:+/-0.13mm(5mil) |
Flexible PCB Capacity
| Item | Capabilities |
| Layers | FPC:1 to 6 Layers, Rigid Flex: 2 to 10 Layers |
| Regular Base Materials | Kapton,Polyimide(PI), Polyester(PET) |
| Base Copper Thickness | 1/3 oz to 8oz |
| Regular Base Material Thickness | 12.5um to 50um(FPC) |
| 0.1mm to 3.2mm(Rigid) | |
| Regular Coverlay Thickness | 27um to 50um |
| Regular Adhesive Thickness | 12um to 25um |
| Blind or Buried Vias | Yes |
| Impedance Control | Yes |
| Min.Line Width/Spacing | 0.04mm/0.04mm |
| Surface Finishing | Electroplate Ni/Au(Flash gold/Soft gold/Hard gold), ENIG, HASL, Immersion Tin,OSP |
| Outline Fabrication | Die cut, laser cut, CNC routing, V-scoring |
| Hole to edge(Hard tool/Die Cut) | ±0.1/±0.2mm |
| Edge to edge(Hard tool/Die Cut) | ±0.05/±0.2mm |
| Circuit to edge(Hard tool/Die Cut) | ±0.07/±0.2mm |
Carbon Oil PCB Capacity
| Carbon Oil PCB Specification | |
| Handle PCB( PS2,XBOX.etc) | |
| Rang of total resistance | 1KΩ-1MΩ |
| Resistance tolerance: | ±20% |
| Resistance to heat : | 260℃ ±5℃ ，5sec，△TR≤±50% |
| Durability: | 1 Million cycles Min |
Automobile component (Use for windscreen wiper. light and air-condition) | |
| Main technical parameter | K-1MΩ |
| Resistance taper: | linear |
| Resistance tolerance: | ±1% |
| Linearity tolerance: | ±1% |
| Durability: | I Million cycles Min |
| TCR: | with ±1000 PPM(-30℃--+70℃) |
| Electricital Component in speed control,etc. | |
| Main technical parameter | RΩ-3MΩ |
| Resistance tolerance: | ±1% |
| Linearity tolerance: | ±1% |
| Durability: | 1 Million cycles Min |
Q1.For PCB quotation, what files format does Xing Da need?
A:Gerber, Protel 99SE, DXP, PADS 9.5, AUTOCAD, CAM350 are OK.
Q2.What is Xing Da's MOQ and fastest delivery time?
A:1pcs. Xing Da can support your project from sample development to mass production.
Q3.How to test PCB boards?
A:AOI, Fly probe testing, Text fixture testing, FOC etc. for bare PCB.
Q4.Which payment terms does Xing Da accept?
A: T/T,Western Union,Paypal, L/C,Credit Card, Cheque,Others
