Immersion Gold Electronic surface mount assembly Car Charger pcba
PCBgate specialize in manufacturing high-reliability PCBA （Printed Circuit Board Assemblies ） specifically for electric vehicle EV-charger (IC-CPD), providing end-to-end solutions that comply with GB/T, IEC and UL standards.
We provide the intelligent electronic core for AC and DC EV-charger, wall boxes, and portable charging cables, ensuring safe, reliable, and smart power delivery.
End-to-End Turnkey Service: We provide a seamless service from component sourcing to SMT assembly, programming, testing, and packaging, simplifying your supply chain.
Immersion Gold Electronic surface mount assembly Car Charger pcba
PCBgate introduction
PCB Product Capacity
Item
Specification
Material
FR-4,FR1, CEM-1, CEM-3,Aluminum, Ceramic, Metal-backed Laminate, etc.Also make Crockery, Taconic, Rogers PCBs etc.
Remarks
High Tg CCL is Available(Tg>=170℃)
Finish Board Thickness
0.2 mm-6.00mm(8mil-126mil)
Surface Finish
Gold finger(>=0.13um), Immersion Gold(0.025-0075um), Plating Gold(0.025-3.0um), HASL(5-20um), OSP(0.2-0.5um)
Shape
Routing、Punch、V-cut、Chamfer
Surface Treatment
Solder Mask(black, green, white, red, blue, thickness>=12um, Block, BGA)
Silkscreen(black, yellow, white)
Peel able-mask(red, blue, thickness>=300um)
Minimum Core
0.075mm(3mil)
Copper Thickness
1/2 oz min; 12oz max
Min Trace Width & Line Spacing
0.075mm/0.1mm(3mil/4mil)
Min Hole Diameter for CNC Drilling
0.1mm(4mil)
Min Hole Diameter for Punching
0.6mm(35mil)
Biggest panel size
2000mm * 700mm
Hole Position
+/-0.075mm(3mil) CNC Drilling
Conductor Width(W)
+/-0.05mm(2mil) or +/-20% of original
Hole Diameter(H)
PTHL:+/-0.075mm(3mil)
Non PTHL:+/-0.05mm(2mil)
Outline Tolerance
+/-0.1mm(5mil) CNC Routing
Warp & Twist
0.70%
Insulation Resistance
10Kohm-20Mohm
Conductivity
<50ohm
Test Voltage
10-300V
Panel Size
110 x 100mm(min)
2000 x 700mm(max)
Layer-layer misregistration
4 layers:0.15mm(6mil)max
6 layers:0.25mm(10mil)max
Min spacing between hole edge to circuitry pattern of an inner layer
0.25mm(10mil)
Min spacing between board outline to circuitry pattern of an inner layer
0.25mm(10mil)
Board thickness tolerance
4 layers:+/-0.13mm(5mil)
PCB Assembly(SMT) Product Capacity
SMT Capacity
SMT Item
Capacity
PCB Max. size
510mm*1200mm(SMT)
Chip component
01005,0201, 0402, 0603, 0805, 1206 package
Min.pin space of IC
0.1mm
Max.precision of IC assembly
±0.01mm
Assembly capacity
≥8 million pionts/day
DIP capacity
6 DIP production lines
Assembly testing
Bridge test,AOI test, X-Ray test, ICT(In Circuit Test)
FCT(Functional Circuit Test)
Current test, voltage test, high temperature and low temperature test,Drop Impact Test,aging test,water proof test,leakage-proof test and etc.Different test can be done according to your requirement.
